Using the Remote Control

Connect the remote control to the unit via the USB cable.

Note

When the remote control is connected, the Power indicator switches on and the other indicators blink for 1 second.

Live	Flashing Blue	The Live operation is starting.
	Fixed Blue	The Live is in progress.
	Off	No Live action is running.
Power	Fixed Green	The remote control is connected to the unit.
	Off	The remote control is not connected to the unit.
Live Button	Short press	When no action is running, starts a Live.
	Long press	When an action is running, stops all actions.
Tally Light	Fixed Red	The Unit is ON Air.
	Off	The Unit is not ON Air.
